The following is a fantastic example of why sometimes, it’s too easy to buy things on eBay…
I didn’t realise until I saw it, but my life had always been missing the ability to print receipts. Several days later, my Citizen CBM-1000 receipt printer arrived.
With no actual ideas for what to use it for, I decided to do the standard geeky thing and used Twitter as a data source.
I coded something quickly in VB6 (because that’s what I happened to have close to hand, and it always makes my day job seem so much more enjoyable after using it and realising that I don’t ever have to.)
Next steps: Make it talk to my Arduino, find something useful for it to do
Since PHP is my language of choice, it wasn’t long before I wanted to use it to control my Arduino.
This turned out to be easier said than done – under Windows anyway, with a lot of vague (mis)information out there. Not to mention a lot of “RTFM” advice.
The way I ended up doing is still a little too hacky for me to be happy with – PHP is clearly the wrong tool for the job here.
PHP has trouble communicating with serial ports – a class is available to handle serial communication for you, but under Windows is write only.
I installed RealTerm, which has a feature to echo a serial port to a TCP/IP port, which PHP has no problem dealing with. Essensially, RealTerm will relay things back and forth between my PHP script and the Arduino.
This worked great, but seems like an unnecessary layer, just for the sake of using PHP.
To test this, I made a simple circuit with two LEDs and a servo, and wrote a quick AJAXy page to control the script, which would send commands to the arduino.
s90 would turn the servo to 90 degrees
g15 would turn the green LED to 15
r0 would turn the red LED off
I made a quick video to show the result
And to show the data being relayed through RealTerm…
EDIT: Forgot to add, this also solves the problem of the Arduino resetting itself every time a serial connection is opened, because RealTerm opens one serial connection and keeps it open, regardless of the actual connections my PHP script makes.
A short year and three months after Nd suggested to me that I should acquire an arduino, mine arrived yesterday.
I went for the starter kit from Earthshine Design because, to be honest, I had no idea what kind of components I would be needing to get started – or even what to build!
The Earthshine kit comes with a nice PDF manual with step by step instructions to build a number of projects with the components supplied.
With that said – let’s get it out of the box
The arduino itself. Oooh shiny.
Enough LEDs to light my entire house
And enough resistors for each of them
And… the rest of the components – many of which I don’t yet understand exactly what they do. Includes a motor, potentiometer, temperature sensor, switches, transistors and so on.
The kit also includes a USB cable to connect the arduino to your computer, a breadboard and jumper wires for easy prototyping (without going to the trouble of soldering etc) and a power adaptor to power the arduino when it’s not plugged in to a computer.
And that’s not to mention the cool case to store your components in!
The kit costs £49.99, which from the research I did, seems to be a good price for such a starter set. With so many components supplied and tutorials for projects to build with them, it’s going to keep me busy for a while.
